SI/PI-Database

The SI/PI-Database is a collection of printed circuit board (PCB) based structures which represent different electromagnetic aspects for signal integrity and power integrity applications. The structures have different components and interconnecting elements e.g. via-arrays, different  planes or dimension. Each structures contains many variations of geometry and material parameters and their respective simulation results. If not stated otherwise, all structures were simulated with a physics-based approach, developed by the Institut für Theoretische Elektrotechnik, and cross validated with a full-wave solver.

Publications related to the Physics-Based Approach of the institute:

Some research results and applications based on the available Data:

Available Datasets

All datasets are described by a sketch and some basic parameters for your orientation, consiting of the following parameters:

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

Size of the compressed Dataset
Total number of simulations
Highest simulated frequency
Number of frequency steps
Number of cavities
Number of simulated ports

If you are interested each dataset also has a detailed description available.

Signal Integrity

SI-1

Link on 11 Cavity PCB with two 10×10 Via-Arrays

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

2.4 GB
7,031
100 GHz
199
11
12

Detailed Desciption ➙

SI-2

Link on 8 Cavity PCB with two 10×10 Via-Arrays

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

2.5 GB
7,031
100 GHz
199
8
12

Detailed Desciption ➙

SI-3

5×5 Via-Array on 10 Cavity PCB

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

12.2 GB
5,000
40 GHz
199
10
34

Detailed Desciption ➙

SI-4

Link on 10 Cavity PCB with two 5×5 Via-Arrays

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

23.7 GB
1,500
40 GHz
334
10
68

Detailed Desciption ➙

SI-5

Universal Single Ended SI Via Array with Latin Hypercube Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

7.5 GB
1,932
100 GHz
400
3-47
6-58

Detailed Desciption ➙

SI-6

Universal Differential SI Via Array with Latin Hypercube Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

6.7 GB
1,916
100 GHz
400
3-47
4-56

Detailed Desciption ➙

SI-7

Universal Differential SI Via Array Link with Latin Hypercube Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

6.8 GB
1,073
100 GHz
400
11-47
8-112

Detailed Desciption ➙

SI-8

14-Layer PCB with 9×8 Via Array – Full Wave

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

390 MB
39
200 GHz
400
13
44

Detailed Desciption ➙

SI-9

Coaxial Via Variation – Full Wave

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

3 MB
72
200 GHz
400
1-8
4

Detailed Desciption ➙

Power Integrety

PI-1

PWR/GND Plane PCB with 11×11 Via-Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

1.3 GB
36,200
1 GHz
334
1
2

Detailed Desciption ➙

PI-2

4-Layer PCB based PDN with two Via Arrays Random Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

44 GB
10,000
1 GHz
334
3
28

Detailed Desciption ➙

PI-3

8-Layer PCB based PDN with two Via Arrays Latin Hypercube Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

42 GB
10,000
1 GHz
334
7
28

Detailed Desciption ➙

PI-4

6-Layer PCB based PDN with two Via Arrays Latin Hypercube Sampling

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

7.2 GB
985
1 GHz
334
5
36

Detailed Desciption ➙

PI-5

4-Layer Polygonal PCB based PDN

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

12 MB
500
1 GHz
334
3
2

Detailed Desciption ➙

PI-6

2-Layer PCB based PDN with Large Via Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

280 MB
10,000
1 GHz
334
1
2

Detailed Desciption ➙

PI-7

4-Layer PCB based PDN with Three Via Arrays – Central Power Rail

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

3.8 GB
20,000
1 GHz
334
3
6

Detailed Desciption ➙

PI-8

4-Layer PCB based PDN with two Via Arrays – Central Power Rail

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

1.7 GB
20,000
1 GHz
334
3
4

Detailed Desciption ➙

PI-9

14-Layer PCB based PDN with two Via Arrays – Central Power Rail

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

1,7 GB
20,000
1 GHz
334
13
4

Detailed Desciption ➙

PI-10

4-Layer Eurocard PCB with Distant Via Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

75 MB
2,000
1 GHz
121
3
4

Detailed Desciption ➙

PI-11

4-Layer Eurocard PCB with Simple Via Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

223 MB
2,000
1 GHz
121
3
8

Detailed Desciption ➙

PI-12

4-Layer Eurocard PCB with Medium Via Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

963 MB
2,000
1 GHz
121
3
18

Detailed Desciption ➙

PI-13

4-Layer Eurocard PCB with Complex Via Array

Size :
NSam :
fmax :
Δf :
NCavs :
NPorts :

16 GB
2,000
1 GHz
121
3
68

Detailed Desciption ➙

To get access to the data please fill out the contact form. You will receive a download link by the entered e-mail address. The zip-archive contains multiple files.First, a description of the structure with explanation regarding the parameter variations. Second, a .csv file which gives an overview over all parameter variations along with classification labels and the simulation index (simu_index). Last, the scattering parameters for the according simulation file is found by the (simu_index) . For each parameter variation a touchstone file simu_index.sNp is available.

Any usage of the data of the SI/PI-Database has to be referenced to the following article:

M. SCHIERHOLZ, A. SANCHEZ-MASIS, A. CARMONA-CRUZ, X. DUAN, K. ROY, C. YANG, R. RIMOLO-DONADIO, C. SCHUSTER,
“SI/PI-Database of PCB-Based Interconnects for Machine Learning Applications”,
IEEE Access, vol. 9, pp. 34423-34432, 2021.
